FLATTENERS & DEWATERING

If you are in the waste or recycling business, paying to ship excess air and liquids will cut deeply into your profit margin. It is of utmost importance to find an efficient and cost-effective way to squeeze both out, maximizing the amount of desirable material in your payloads. Komar offers a wide range of equipment solutions to slash your transportation costs. Komar units provide proven compaction ratios of 4-7 times on containers and dewatering results of 50 to 85% depending upon application.

Types

  • FLATTENERS

    Container compactors for PET, HDPE, Aluminum Containers as well as Gable Top and TetraPak

  • DE-WATERERS

    De-watering units for paper mills, municipal solid waste, and beverage containers

Flatteners

EPC series Flattener
Auger Type:
Electromechanical, Stationary
Facilities:
Bottle and Can Deposit or Drop-Off Centers, Bottle and Can Baling Operations
Application:
Bottles, Cans, and Cartons
Volume:
Low low volume processing
Duty:
Continuous
Feed Methods:
Hand, Conveyor
Models:
EPC-5, EPC-7.5

With only three major moving parts, the EPC product line redefines simple, reliable product compression.  This technology compacts capped PET bottles with ease as well as HDPE, aluminum cans and other recyclable containers.  Utilizing clean all-electric drives this series provides quiet, low maintenance operation.

  • Compresses products 700%, slashing transportation costs
  • Speeds downstream baling by over 50%
  • Locates adjacent to buy back point to reduce site handling costs
  • Improves downstream manual and automated sorting accuracy
  • Low power consumption: can run on single or three phase
  • Fully prewired, ready to run
  • Ultra abrasion resistant metallurgy
  • Can be configured as a standalone unit, a cartridge for insertion into a material recovery facility’s process line, or under a high speed container sorting system
EPC 5 Specifications
weight 2,100 lbs
rpm 43
hp 5
base machine (l x w x h) 16’7″ (maximum) x 46″ (maximum) x 8’6″
Compaction PET: Adjustable 4-6 to 1
Aluminum: 3.5 to 1
Throughput/hr PET: 700-1,000 lbs/hr
Aluminum: Up to 800 lbs/hr
Conveyor Load Height 42″
Product Discharge Height 60″
EPC 7.5 Specifications
weight 2,100 lbs
rpm 63
hp 7.5
base machine (l x w x h) 16’7″ (maximum) x 46″ (maximum) x 8’6″
Compaction PET: Adjustable 4-6 to 1
Aluminum: 3.5 to 1
Throughput/hr PET: 1,000‐1,500 lbs/hr
Aluminum: 1,300‐1,500 lbs/hr
Conveyor Load Height 42″
Product Discharge Height 60″
BC stationary series Flattener
Auger Type:
Electromechanical, Stationary
Facilities:
Bottle and Can Recycling Facilities, Bottle and Can Producers
Application:
Bottles and Cans
Volume:
Medium medium volume processing
Duty:
Continuous
Feed Methods:
Conveyor, Tipper, Forklift
Models:
EPC-40

When you require very high throughput rates, it is time to consider Komar’s EPC-40. Designed for large scale operations, the EPC-40 can process up to 8,000 lbs/hr, at adjustable compaction rates of 4-8 times. The EPC-40 can handle capped bottles with ease and produces singulated, intact product for available optical sorting.

  • Handles 8,000 lbs. of plastic per hour
  • Adjustable compaction rates of 400%-800%
  • Compact footprint inserts into existing process conveyor lines
  • Can be mounted on stand to rear load transfer trailers up to 40,000 lbs.
  • Speeds downstream baling by 50%,
  • Reduces bale wire use by 30%, improves bale weights by up to 20%
  • Durable, clean, low maintenance operation
  • Dewatering option for high volume product destruction
EPC 40 Specifications
weight 10,300 lbs
rpm 20
hp 40
base machine (l x w x h) 11’5″ x 9′ x 4’8″
Compaction 4 to 6 to 1 – Adjustable
PET Throughput/hr 8,000 lbs/hr.

Larger 60hp units are available to 12,000 lbs/hr

Portable PET Flattening
Auger Type:
HydroMechanical, Portable
Facilities:
Bottle and Can Deposit Recycling Centers
Application:
Bottle and Cans
Volume:
High high volume processing
Duty:
Continuous
Feed Methods:
Integrated Rear Tipper
Models:
EPC-150

The current collection method of servicing depot systems in North America, collecting un-compacted bags of deposit containers in dry vans, is both time-consuming and expensive. High cost operations are due to labor-intensive loading and stacking operations, the necessity to ship back empty bags, and the resultant light payloads transported to processors. The EPC-150 compaction trailer rewrites the rules of PET collection by loading up to 4 tote bags per minute and carrying up to 30,000 lbs. of compacted aluminum cans or plastic bottles.

  • Rapid rear tipping system tips 2 bags per cycle, handling 4 yds per minute
  • Loads, compacts and compresses containers into trailer body in a single operation
  • Carries up to 30,000 lbs of compacted containers
  • Eliminates the need for small collection vans, and tote bag handling at collection centers
  • Reduces offloading time to 10 minutes, eliminating all site labor
  • Speeds up baling by 60%, can also be used to deliver compacted material directly to end processor
  • Trailer package includes sound proofed engine compartment with exhaust silencer
  • Optional equipment includes auto weigh system, GPS location tracking, EWON report support and automatic maintenance reminders
EPC 150 Specifications
engine type diesel
payload weight Up to 30,000 lbs depending upon local GVWR
hp 150
base machine (l x w x h) 53′ x 13’6″ x 8’5″
Compaction 4 to 1 for Aluminum Cans, 6-10 to 1 for PET Containers
PET Throughput/hr Up to 12,000 lbs/hr (4 cubic yards per minute)

Dewaterers

Dewaterer
Auger Type:
Electromechanical, Stationary
Facilities:
Paper Mills, Industrial Depackaging, MSW and Organic Dewatering
Application:
Dewatering
Volume:
Medium medium volume processing
Duty:
Continuous
Feed Methods:
Forklift, Conveyor, Tipper
Models:
EM-40D (with dewatering unit)

Komar’s robust EM-40D auger, coupled with the proprietary maintenance free wedge bar de-watering system dramatically reduces hauling costs. This unique system leverages the EM-40D’s unrivaled 178,000 lbs. of thrust to create a compaction force that has demonstrated water removal rates of up to 85% from process reject streams. Proven applications include pulp mill rejects, industrial water jet fabric offcuts, organic separation residuals and dewatering of MSW.

  • Reduces transport weights and landfill costs by up to 80%
  • Feeds up to 15 wet tons per hour
  • Self-cleaning wedge bar design minimizes blinding and ensures easy start-up
  • Handles oversized items and wire with ease
  • An ideal choice for both batch and continuous operations
  • Automated dewatering pressure gate applies consistent pressure for maximum results
  • The simplicity of design dramatically lowers lifecycle costs and allows for easy scheduled maintenance turnarounds
  • System paybacks of 1 to 2 years are common
  • Systems can be fed by forklift, tipper or conveyor and can discharge into conveyors, compactors, roll-off boxes or trailers
EM-40D Specifications
weight 17,750 lbs
hp 40
base machine (l x w x h) 14’4″ x 8’3″ x 7’10”
Free liquid removal 80% to 90% depending upon application
Throughput/hr 15,000 to 30,000 lbs/hr depending upon feed method

Available with optional hydrostatic drive system for high volume continuous operations.

Dewaterer
Auger Type:
Electromechanical, Stationary
Facilities:
Manufacturers, Organics Collection Companies
Application:
Dewatering, Bottles and Cans, Carton
Volume:
Medium medium volume processing
Duty:
Continuous
Feed Methods:
Forklift, Conveyor, Tipper

This solution is designed for an off-spec or expired product that still has value to other markets.  This unit replaces traditional perforators, with its unmatched ability to process an entire pallet of full containers per minute (equivalent to 216 gallons of liquid).  As the auger screw ruptures the containers, the liquid drains through the holes in the bottom of the processing chamber and into a containment area.

  • Processes 216 gallons per minute
  • Perfect for the destruction of offspec or expired product
  • Liquid is collected and resold to secondary markets, dried containers are segregated and discharged for baling or transportation
Contact factory for model specifications: 614-836-2366
